What is Impact Resistant Conveyor Belt
Specifically designed to provide strong resistance against objects that might rip through the belt, impact-resistant conveyor belts are used for carrying jagged materials in heavy-duty conditions, especially where large drop heights are involved. Impact-resistant belts operate effectively in this environment due to a special textile or metal weave, known as a breaker.The rubber covers are equipped to handle the impact, minimise rips and tears, resist aggressive wear and reduce gouging and cutting caused by hard, sharp materials.
Product Use
Impact resistant conveyor belts are recommended for carrying lumpy, jagged materials in heavy duty conditions. These types of conveyor belts feature high impact and tear resistance provided by a special textile or metal weave called a breaker. The type of breaker used to manufacture rip and impact resistant conveyor belts differs depending on the application. For increasing lateral strength, high elongation steel mesh is used as weft cord. For increasing lateral stiffness, regular steel mesh can be used. Breaker material is also available as a fabric weave with increased tear and impact resistance for lighter working conditions where steel is not required.
Product Features
Excellent resistance to cuts and abrasion
Long-lasting impact resistance with minimal belt damage
Excellent resistance to sandwiching
Standard and made-to-order products are available
Product Use
Impact resistant conveyor belts are recommended for carrying lumpy, jagged materials in heavy duty conditions. These types of conveyor belts feature high impact and tear resistance provided by a special textile or metal weave called a breaker. The type of breaker used to manufacture rip and impact resistant conveyor belts differs depending on the application. For increasing lateral strength, high elongation steel mesh is used as weft cord. For increasing lateral stiffness, regular steel mesh can be used. Breaker material is also available as a fabric weave with increased tear and impact resistance for lighter working conditions where steel is not required.
Executive Standard
China GB/T7984 Standard
Germany DIN22102 Standard
US RMA Standard
UK EN ISO15236 Standard
Japan JISK6322 Standard
Australia AS1332 Standard
Main Technical Parameters
STEADFAST STANDARD | DIN QUALITY | TENSILE STRENGTH | ELONGATION AT BREAK | ABRASION LOSS | BASE POLYMER | TECHNICAL FEATURES APPLICATION AREA |
Abrasion resistant | DIN W | 180 | 400 | 90 | NR/ SBR | Abrasion resistant covers provide a very high level of abrasion and cut and tear resistant.
These kinds of rubber covers also feature good weather resistance. |
| DIN X | 250 | 450 | 120 | NR/ SBR | Abrasion resistant covers provide a very high level of abrasion and cut and tear resistant.
These kinds of rubber covers also feature good weather resistance. |
| DIN Y | 200 | 400 | 150 | SBR | Used for general use applications with superior resistance to abrasion, weather and cuts. |
FAQ
Q1. How about your experience?
We have mainly produced rubber conveyor belts for over 20 years.
Q2. What are your main products?
Multi-ply fabric conveyor belt(EP/NN type), steel cord conveyor belt, chevron conveyor belt, sidewall belt, white conveyor belt, bucket elevator belt, filter belt, and special conveyor belts with the characteristics of heat resistant, cold resistant, oil resistant, flame retardant, abrasion resistant, etc.
Q3. What about the lead time?
1) 3--5 days for sample.
2) 20--25 days for mass production. If urgent, we have the green channel.
Q4. Can you send free samples?
Yes, we provide samples for free after inquiry.
Q5. How about the package?
Standard export packing method, your special requirement will be respected.
Q6. What are your Payment terms?
T/T or L/C.
Q7. Can you do door-to-door?
No problem.
Q8. How do you ensure your product quality?
Our quality control system had been ISO9001 certified. The first-class production equipment, testing facilities, and a complete quality assurance system guarantee high quality.
Q9. What is your major market?
Our products are heavily involved in exporting all over the world, including Europe, America, the Middle East, Southeast Asia, South Africa, Australia, etc.
Q10. What you can do to support me better?
We can provide products that meet quality standards, timely delivery, transportation packaging requirements, and customers' other special requirements.
